规格: | |
---|---|
Quantity: | |
KEMPPI TWGX403W/405W
Tonyweld
85159000
KEMPPI TWGX403W/405W Water Cooled MIG GUN
KEMPPI TWGX403W/405W Water welding torch
1piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
400A Mixed Gases
100%
euro / miller /bernard connector and etc
0.8-1.6MM
TWGX403W/405W WATER COOLED MIIG GUN | ||
Technical Data: | Rating : 400A Mixed Gases | |
| Duty Cycle : 100% | |
| Wire Size : 0.8-1.6MM | |
| | |
No. | Description | Order |
| TWGX403W Water Cooled MIG Gun 3.5m | TWGX403W35 |
| TWGX403W Water Cooled MIG Gun 5.0m | TWGX403W50 |
| TWGX405W Water Cooled MIG Gun 3.5m | TWGX405W35 |
| TWGX405W Water Cooled MIG Gun 5.0m | TWGX405W50 |
| | |
A | TWGX30G/GX40W Nozzle ф15*57 OD:25mm | TWW011478 |
| TWGX30G/GX40W Nozzle ф16*61 OD:25mm | TWW013930 |
| TWGX30G/GX40W Nozzle ф19*61 OD:25mm | TWW012143 |
| TWGX30G/GX40W Nozzle ф15*57 OD:25mm Nickel | TWW021173 |
| TWGX30G/GX40W Nozzle ф16*61 OD:25mm Nickel | TWW021179 |
B | TWGX Contact Tip E-CU M10*28mm | TWCT**C1SD001 |
| TWGX Contact Tip E-CU Stainless M10*28 | TWCT**C2SD001 |
| TWGX Contact Tip E-CU Aluminum M10*28 | TWCT**C3SD001 |
| TWGX Contact Tip CuCrZr M10*28 | TWCT**C1CZ001 |
| TWGX Contact Tip CuCrZr Stainless M10*28 | TWCT**C2CZ001 |
| TWGX Contact Tip CuCrZr Aluminum M10*28 | TWCT**C3CZ001 |
C | Contact Tip Adapter M10 Insulated | TWW013203 |
D | Contact Tip Adapter M10 Brass | TWW011483 |
E | TWGX Steel 3.5m 0.9-1 .2mm Fe G/W | TWW013628 |
| TWGX Steel 5.0m 0.9-1.2mm Fe G/W | TWW013632 |
F | TWGX DL Chili 3.5m 1.0-1.2mm AI, Ss, Fe G | TWW007677 |
| TWGX DL Chili 5.0m 1.0-1.2mmAI, Ss, Fe G | TWW007680 |
| | |
No. | Description | Order |
1 | TWGX40W Swan Neck | TWSP012594 |
2 | Handle TWGX | TWSP800906 |
3 | Switch TWGX3 | TWSP022336 |
4 | Switch TWGX5 | TWSP022293 |
5 | Pistol Grip Handle | TWSP014683 |
6 | TWGXR10 Gun Remote | TWGXR10 |
7 | Connector Hoder With Wire TWGX5 | TWSP800899 |
8 | Water Current Cable 3.5m | TWSP012069 |
| Water Current Cable 5.0m | TWSP015372 |
9 | Wire Conduit ф7x9 | TW9370166 |
9-1 | Hose Clamp ф9.5 | TWSP9377123 |
10 | Water/Gas Hose ф4x7 | TW9370184 |
10-1 | Hose Clamp ф8.0 | TWSP9377119 |
11 | Control Wire 4-pole 3.5m | TWSP015350 |
| Control Wire 4-pole 5.0m | TWSP015344 |
12 | Protective Hose ф28x1.5 Ball Joints Are Included 3.5m | TWSP800903 |
| Protective Hose ф28x1.5 Ball Joints Are Included 5.0m | TWSP800902 |
13 | Support Spring | TWSP801082 |
14 | Cover For Connector Water Gun | TWSP801087 |
15 | Protection Spring For Water Hose | TWSP011994 |
16 | Blocking Plug Blud | TWSP4298560 |
17 | Blocking Plug Red | TWSP4298550 |
18 | Snap Connector Spindle D9-4ML | TWSP4270440 |
19 | Locking Nut Euro Connector | TWSP014840 |
20 | Euro Connector Water | TWSP014619 |
21 | Jacket Nut Euro ID7.9mm | TWSP014605 |
22 | End Cap 4.9mm Sealed | TWSP016214 |
TWGX403W/405W WATER COOLED MIIG GUN | ||
Technical Data: | Rating : 400A Mixed Gases | |
| Duty Cycle : 100% | |
| Wire Size : 0.8-1.6MM | |
| | |
No. | Description | Order |
| TWGX403W Water Cooled MIG Gun 3.5m | TWGX403W35 |
| TWGX403W Water Cooled MIG Gun 5.0m | TWGX403W50 |
| TWGX405W Water Cooled MIG Gun 3.5m | TWGX405W35 |
| TWGX405W Water Cooled MIG Gun 5.0m | TWGX405W50 |
| | |
A | TWGX30G/GX40W Nozzle ф15*57 OD:25mm | TWW011478 |
| TWGX30G/GX40W Nozzle ф16*61 OD:25mm | TWW013930 |
| TWGX30G/GX40W Nozzle ф19*61 OD:25mm | TWW012143 |
| TWGX30G/GX40W Nozzle ф15*57 OD:25mm Nickel | TWW021173 |
| TWGX30G/GX40W Nozzle ф16*61 OD:25mm Nickel | TWW021179 |
B | TWGX Contact Tip E-CU M10*28mm | TWCT**C1SD001 |
| TWGX Contact Tip E-CU Stainless M10*28 | TWCT**C2SD001 |
| TWGX Contact Tip E-CU Aluminum M10*28 | TWCT**C3SD001 |
| TWGX Contact Tip CuCrZr M10*28 | TWCT**C1CZ001 |
| TWGX Contact Tip CuCrZr Stainless M10*28 | TWCT**C2CZ001 |
| TWGX Contact Tip CuCrZr Aluminum M10*28 | TWCT**C3CZ001 |
C | Contact Tip Adapter M10 Insulated | TWW013203 |
D | Contact Tip Adapter M10 Brass | TWW011483 |
E | TWGX Steel 3.5m 0.9-1 .2mm Fe G/W | TWW013628 |
| TWGX Steel 5.0m 0.9-1.2mm Fe G/W | TWW013632 |
F | TWGX DL Chili 3.5m 1.0-1.2mm AI, Ss, Fe G | TWW007677 |
| TWGX DL Chili 5.0m 1.0-1.2mmAI, Ss, Fe G | TWW007680 |
| | |
No. | Description | Order |
1 | TWGX40W Swan Neck | TWSP012594 |
2 | Handle TWGX | TWSP800906 |
3 | Switch TWGX3 | TWSP022336 |
4 | Switch TWGX5 | TWSP022293 |
5 | Pistol Grip Handle | TWSP014683 |
6 | TWGXR10 Gun Remote | TWGXR10 |
7 | Connector Hoder With Wire TWGX5 | TWSP800899 |
8 | Water Current Cable 3.5m | TWSP012069 |
| Water Current Cable 5.0m | TWSP015372 |
9 | Wire Conduit ф7x9 | TW9370166 |
9-1 | Hose Clamp ф9.5 | TWSP9377123 |
10 | Water/Gas Hose ф4x7 | TW9370184 |
10-1 | Hose Clamp ф8.0 | TWSP9377119 |
11 | Control Wire 4-pole 3.5m | TWSP015350 |
| Control Wire 4-pole 5.0m | TWSP015344 |
12 | Protective Hose ф28x1.5 Ball Joints Are Included 3.5m | TWSP800903 |
| Protective Hose ф28x1.5 Ball Joints Are Included 5.0m | TWSP800902 |
13 | Support Spring | TWSP801082 |
14 | Cover For Connector Water Gun | TWSP801087 |
15 | Protection Spring For Water Hose | TWSP011994 |
16 | Blocking Plug Blud | TWSP4298560 |
17 | Blocking Plug Red | TWSP4298550 |
18 | Snap Connector Spindle D9-4ML | TWSP4270440 |
19 | Locking Nut Euro Connector | TWSP014840 |
20 | Euro Connector Water | TWSP014619 |
21 | Jacket Nut Euro ID7.9mm | TWSP014605 |
22 | End Cap 4.9mm Sealed | TWSP016214 |
