KEMPPI TWGX403G/405G Gas Cooled MIG GUN and mig consumables

Share to:

TWGX403G/405G Gas Cooled MIG GUN Technical Data： Rating : 400A Mixed Gases Duty Cycle : 35% Wire Size : 0.8-1.4MM

规格:	KEMPPI TWGX303G/305G Gas cooled WHOEL TORCH
Quantity:



Inquire Add to Basket

Model:
KEMPPI TWGX403G/405G Gas
Brand:
Tonyweld
Code:
85159000
Product Name :
KEMPPI TWGX403G/405G Air Cooled MIG GUN
series :
KEMPPI TWGX403G/405G Gas torch
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
400A Mixed Gases
Duty Cycle :
35%
connector :
euro / miller /bernard connector and etc
wire size :
0.8-1.6MM

Product Description

Kemppi TWGX403G/405G Air Cooled MIG GUN And Mig consumables

Kemppi-8

Kemppi TWGX403G/405G Air Cooled MIG GUN mig welding consumables .

TWGX403G/405G GAS COOLED MIIG GUN
Technical Data：	Rating : 400A Mixed Gases
	Duty Cycle : 35%
	Wire Size : 0.8-1.6MM

No.	Description	Order
	TWGX403G Gas Cooled MIG Gun 3.5m	TWGX403G35
	TWGX403G Gas Cooled MIG Gun 5.0m	TWGX403G50
	TWGX405G Gas Cooled MIG Gun 3.5m	TWGX405G35
	TWGX405G Gas Cooled MIG Gun 5.0m	TWGX405G50

A	TWGX40G/GX50W Nozzle ф15*60 OD:28mm	TWW011472
	TWGX40G/GX50W Nozzle ф17*64 OD:28mm	TWW013931
	TWGX40G/GX50W Nozzle ф21*64 OD:28mm	TWW012146
	TWGX40G/GX50W Nozzle ф15*60 OD:28mm Nickel	TWW021182
	TWGX40G/GX50W Nozzle ф17*64 OD:28mm Nickel	TWW021186
B	Contact Tip Adapter M10 Insulated	TWW013203
C	Contact Tip Adapter M10 Brass	TWW011483
D	TWGX Contact Tip E-CU M10*28mm	TWCT**C1SD001
	TWGX Contact Tip E-CU Stainless M10*28	TWCT**C2SD001
	TWGX Contact Tip E-CU Aluminum M10*28	TWCT**C3SD001
	TWGX Contact Tip CuCrZr M10*28	TWCT**C1CZ001
	TWGX Contact Tip CuCrZr Stainless M10*28	TWCT**C2CZ001
	TWGX Contact Tip CuCrZr Aluminum M10*28	TWCT**C3CZ001
E	TWGX Steel 3.5m 0.9-1.2mm Fe G/W	TWW013628
	TWGX Steel 5.0m 0.9-1.2mm Fe G/W	TWW013632
	TWGX DL Chili 3.5m 1.2-1.6mm Al, Ss, Fe G	TWW007681
	TWGX DL Chili 5.0m 1.2-1.6mm Al, Ss, Fe G	TWW007683

No.	Description	Order
1	TWGX40G Swan Neck	TWSP014666
2	Neck Tightener	TWSP014800
3	Handle TWGX	TWSP800906
4	Switch TWGX3	TWSP022336
5	Switch TWGX5	TWSP022293
6	Pistol Grip Handle	TWSP014683
7	TWGXR10 Gun Remote	TWGXR10
8	Connector Hoder With Wire TWGX5	TWSP800899
9	Cable Assembly 3.5m	TWGX3035
	Cable Assembly 5.0m	TWGX3050
10	Control Wire 4-pole 3.5m	TWSP01 5350
	Control Wire 4-pole 5.0m	TWSP015344
11	Protective Hose ф28x1.5 Ball Joints Are Included 3.5m	TWSP800903
	Protective Hose ф28x1.5 Ball Joints Are Included 5.0m	TWSP800902
12	Support Spring	TWSP801082
13	Cover For Connector Gas Gun	TWSP801083
14	Locking Nut Euro Connector	TWSP014840
15	Euro Connector Gas	TWSP014842
16	Jacket Nut Euro ID7.9mm	TWSP014605
17	End Cap 4.9mm Sealed	TWSP016214

Kemppi TWGX403G/405G Air Cooled MIG welding torch package
Kemppi-4

* 1 piece Kemppi TWGX403G/405G Air Cooled MIG welding torch 400A package in a carton
