Product Category

KEMPPI MT38 Air Cooled MIG GUN and mig consumables

Share to:

MT38 Air Cooled MIG GUN Technical Data： Rating : 300A CO2 Duty Cycle : 35% Wire Size : 0.8-1.6MM

规格:	KEMPPI MT38 WHOEL TORCH
Quantity:



Inquire Add to Basket

Model:
KEMPPI MT38
Brand:
Tonyweld
Code:
85159000
Product Name :
KEMPPI MT38 Air Cooled MIG GUN and mig consumables
series :
KEMPPI MT38 torch
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
300A CO2
Duty Cycle :
35%
connector :
euro / miller /bernard connector and etc
wire size :
0.8-1.6MM

Product Description

Kemppi MT38 Air Cooled MIG GUN And Mig consumables
Kemppi-20

Kemppi MT38 Air Cooled MIG GUN mig welding consumables .

MT38 Air Cooled MIG GUN
Technical Data：	Rating : 300A CO2
	Duty Cycle : 35%
	Wire Size : 0.8-1.6MM

No.	Description	Order
	MT38 Air Cooled Mig GUN 3.5m	TW6253038
	MT38 Air Cooled Mig GUN 5.0m	TW6253039

A	Nozzle ф12.5*86	TW4255530
	Nozzle ф16*90	TW425530E
	Nozzle ф16*86	TW4273510
B	Nozzle Insulating bush	TW4248710
C	Contact Tip M8 .030” 0.8mm	TW9580122
	Contact Tip M8 .035” 0.9mm	TW9580121
	Contact Tip M8 .039” 1.0mm	TW9580123
	Contact Tip M8 .045” 1.2mm	TW9580124
	Contact Tip M8 .052” 1.4mm	TW9580125
	Contact Tip M8 1/16” 1.6mm	TW9580126
	Contact Tip M8 5/64” 2.0mm	TW9580127
	Contact Tip M8 3/32” 2.4mm	TW9580128
D	Contact tip adapter M8	TW4255421
	Wire Liner 0.9-1.2mm 3.0m/Red	TW4188581
	Wire Liner 0.9-1.2mm 4. 5m/Red	TW4188582
	Wire Liner 0.9-1.2mm 3.5m/Red	TWW006453
	Wire Liner 0.9-1.2mm 5.0m/Red	TWW006454
E-1	DL Chili-Teflon Liner 1.0-1.2mm 3.0m	TWW005921
	DL Chili-Teflon Liner 1.0-1.2mm 4.5m	TWW005938
	DL Chili-Teflon Liner 1.0-1.2mm 3.5m	TWW007961
	DL Chili-Teflon Liner 1.0-1.2mm 5.0m	TWW007962

No.	Description	Order
1	Swan Neck 45°	TW3127990
1-1	Insulating Ring Swan Neck	TW4254670
2	Swan Neck Spring
3	Front Handle
4	Switch	TW4182500
5	Cable Assembly
6	Switch control wire plug
7	Cover ф23x1.5
8	Rear Cable Support .	TW3137900
9	Rear Handle	TW4270500
10	Rear Connector Nut	TW9592105
11	Kemppi Euro Central Connector	TW9580159
12	Jacket Nut	TWSP9580158

Kemppi MT38 Air Cooled MIG welding torch package

* 1 piece Kemppi MT38 Air Cooled MIG welding torch 600A package in a carton
