KEMPPI MMT/PMT42 Air Cooled MIG GUN
Tonyweld
85159000
KEMPPI MMT/PMT42 Air Cooled MIG GUN and mig consu
KEMPPI MMT/PMT42 torch
1piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
420A Mixed Gases
35%
euro / miller /bernard connector and etc
0.8-1.6mm
MMT/PMT42 Air Cooled MIG GUN | ||
Technical Data: | Rating: 420A CO2 | |
| Duty Cycle:35% | |
| Wire Size:0.8-1.6mm | |
| | |
No. | Description | Order |
| MMT42 MIG GUN Air Cooled 3.0m | 6254213MMT |
| MMT42 MIG GUN Air Cooled 4.5m | 6254214MMT |
| PMT42 MIG GUN Air Cooled 3.0m | 6254213 |
| PMT42 MIG GUN Air Cooled 4.5m | 6254214 |
| | |
A | Nozzle With Insulating Ring φ18*80 | 4307070 |
| Nozzle Standard φ18*80 | 4300380 |
| Nozzle Long φ18*83 | 4300380L |
| Nozzle Conical φ14*80 | 4300380C |
| Nozzle Special Long φ18*89.5 | 4308190 |
A-1 | Nozzle Insulating Bush | 4307030 |
B | Contact Tip M8 .030” 0.8mm | 9580122 |
| Contact Tip M8 .035” 0.9mm | 9580121 |
| Contact Tip M8 .039” 1.0mm | 9580123 |
| Contact Tip M8 .045” 1.2mm | 9580124 |
| Contact Tip M8 .052” 1.4mm | 9580125 |
| Contact Tip M8 1/16” 1.6mm | 9580126 |
| Contact Tip M8 5/64” 2.0mm | 9580127 |
| Contact Tip M8 3/32” 2.4mm | 9580128 |
C | Contact Tip Adapter M8 | 4304600 |
D | Gas Diffuser DMC | W004505 |
E | Wire Liner 0.9-1.2mm 3.0m/Red | 4188581 |
| Wire Liner 0.9-1.2mm 4.5m/Red | 4188582 |
| Wire Liner 0.9-1.2mm 3.5m/Red | W006453 |
| Wire Liner 0.9-1.2mm 5.0m/Red | W006454 |
E-1 | DL Chili -Teflon Liner 1.0-1.2mm 3.0m | W005921 |
| DL Chili -Teflon Liner 1.0-1.2mm 4.5m | W005938 |
| DL Chili -Teflon Liner 1.0-1.2mm 3.5m | W007961 |
| DL Chili -Teflon Liner 1.0-1.2mm 5.0m | W007962 |
| | |
No. | Description | Order |
1 | Swan Neck 50° | SP004578 |
2 | Front Handle | 4270490 |
2-1 | Connecting Ring | 4266500 |
3 | Switch | 4182500 |
4 | Cable Assembly 3m 4.5m | |
5 | Switch control wire plug | |
6 | Link Piece | 3146280A |
6-1 | Cable Support | 3133490 |
7 | Cover φ23×1.5 | |
8 | Rear Cable Support | 3137900 |
9 | Rear Handle | 4270500 |
10 | Rear Connector Nut | 9592105 |
11 | Kemppi Euro Central Connector | 9580159 |
12 | Jacket Nut | SP9580158 |
MMT/PMT42 Air Cooled MIG GUN | ||
Technical Data: | Rating: 420A CO2 | |
| Duty Cycle:35% | |
| Wire Size:0.8-1.6mm | |
| | |
No. | Description | Order |
| MMT42 MIG GUN Air Cooled 3.0m | 6254213MMT |
| MMT42 MIG GUN Air Cooled 4.5m | 6254214MMT |
| PMT42 MIG GUN Air Cooled 3.0m | 6254213 |
| PMT42 MIG GUN Air Cooled 4.5m | 6254214 |
| | |
A | Nozzle With Insulating Ring φ18*80 | 4307070 |
| Nozzle Standard φ18*80 | 4300380 |
| Nozzle Long φ18*83 | 4300380L |
| Nozzle Conical φ14*80 | 4300380C |
| Nozzle Special Long φ18*89.5 | 4308190 |
A-1 | Nozzle Insulating Bush | 4307030 |
B | Contact Tip M8 .030” 0.8mm | 9580122 |
| Contact Tip M8 .035” 0.9mm | 9580121 |
| Contact Tip M8 .039” 1.0mm | 9580123 |
| Contact Tip M8 .045” 1.2mm | 9580124 |
| Contact Tip M8 .052” 1.4mm | 9580125 |
| Contact Tip M8 1/16” 1.6mm | 9580126 |
| Contact Tip M8 5/64” 2.0mm | 9580127 |
| Contact Tip M8 3/32” 2.4mm | 9580128 |
C | Contact Tip Adapter M8 | 4304600 |
D | Gas Diffuser DMC | W004505 |
E | Wire Liner 0.9-1.2mm 3.0m/Red | 4188581 |
| Wire Liner 0.9-1.2mm 4.5m/Red | 4188582 |
| Wire Liner 0.9-1.2mm 3.5m/Red | W006453 |
| Wire Liner 0.9-1.2mm 5.0m/Red | W006454 |
E-1 | DL Chili -Teflon Liner 1.0-1.2mm 3.0m | W005921 |
| DL Chili -Teflon Liner 1.0-1.2mm 4.5m | W005938 |
| DL Chili -Teflon Liner 1.0-1.2mm 3.5m | W007961 |
| DL Chili -Teflon Liner 1.0-1.2mm 5.0m | W007962 |
| | |
No. | Description | Order |
1 | Swan Neck 50° | SP004578 |
2 | Front Handle | 4270490 |
2-1 | Connecting Ring | 4266500 |
3 | Switch | 4182500 |
4 | Cable Assembly 3m 4.5m | |
5 | Switch control wire plug | |
6 | Link Piece | 3146280A |
6-1 | Cable Support | 3133490 |
7 | Cover φ23×1.5 | |
8 | Rear Cable Support | 3137900 |
9 | Rear Handle | 4270500 |
10 | Rear Connector Nut | 9592105 |
11 | Kemppi Euro Central Connector | 9580159 |
12 | Jacket Nut | SP9580158 |
