binzel mb 36KD
Tonyweld
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch
| Flexible Swan Neck Mig Welding Torches Binzel Removable Pistol Grip Mb 36KD Co2 Gas Air Cooled Gun Torch Technical Data |
| TW36KD Air Cooled MIG Welding Torch | ||
| Technical Data: | ||
| Rating: 320A CO2/290A Mixed Gases | ||
| Duty Cycle: 60% | ||
| Wire Size:0.8-1.2mm | ||
| No. | Description | Order |
| TW36KD 3m Welding Torch | TW014.0334 | |
| TW36KD 4m Welding Torch | TW014.0335 | |
| TW36KD 5m Welding Torch | TW014.0336 | |
| A | Nozzle Tapered Φ12*84 | TW145.0126 |
| Nozle Conical Φ16*84 | TW145.0078 | |
| Nozzle Cylindrical Φ19*84 | TW145.0045 | |
| B | Contact Tip E-CU M8*30*0.8mm | TW140.0114 |
| Contact Tip E-CU M8*30*1.0mm | TW140.0313 | |
| Contact Tip E-CU M8*30*1.2mm | TW140.0442 | |
| Contact Tip E-CU M8*30*1.4mm | TW140.0533 | |
| Contact Tip E-CU M8*30*1.6mm | TW140.0587 | |
| Contact Tip E-CU M8*30*2.0mm | TW140.0653 | |
| Contact Tip E-CU M8*30*2.4mm | TW140.0677 | |
| Contact Tip CuCrZr M8*30*0.8mm | TW140.0117 | |
| Contact Tip CuCrZr M8*30*1.0mm | TW140.0316 | |
| Contact Tip CuCrZr M8*30*1.2mm | TW140.0445 | |
| Contact Tip CuCrZr M8*30*1.4mm | TW140.0536 | |
| Contact Tip CuCrZr M8*30*1.6mm | TW140.0590 | |
| Contact Tip CuCrZr M8*30*2.0mm | TW140.0656 | |
| Contact Tip CuCrZr M8*30*2.4mm | TW140.0679 | |
| Contact Tip E-CU Aluminum M8*30*0.8mm | TW141.0003 | |
| Contact Tip E-CU Aluminum M8*30*1.0mm | TW141.0008 | |
| Contact Tip E-CU Aluminum M8*30*1.2mm | TW141.0015 | |
| Contact Tip E-CU Aluminum M8*30*1.4mm | TW141.0055 | |
| Contact Tip E-CU Aluminum M8*30*1.6mm | TW141.0022 | |
| Contact Tip E-CU Aluminum M8*30*2.0mm | TW141.0033 | |
| C | Contact Tip Holder M6*28 | TW142.0005 |
| Contact Tip Holder M6*32 | TW142.0011 | |
| Contact Tip Holder M8*28 | TW142.0020 | |
| Contact Tip Holder M8*34 | TW142.0024 | |
| D | Gas Diffuser DMC | TW014.0261 |
| Gas Diffuser Ceramic | TW014.0023 | |
| E | Yellow Steel Liner 1.2-1.6mm 3m | TW124.0041 |
| Yellow Steel Liner 1.2-1.6mm 4m | TW124.0042 | |
| Yellow Steel Liner 1.2-1.6mm 5m | TW124.0044 | |
| No. | Description | Order |
| 1 | Swan Neck | TW014.0006 |
| 1-1 | AUT 36KD 0° Swan Neck | TW914.0002 |
| 2 | Front Handle | TW180.D078 |
| 3 | Switch | TW1850031S |
| 4 | Cable Ball Joint & Support Spring Middle | TW400.1010M |
| 5 | TW 36KD Power Cable 3m 35mm2 | TW160.0364 |
| TW 36KD Power Cable 4m 35mm2 | TW160.0379 | |
| TW 36KD Power Cable 5m 35mm2 | TW160.0391 | |
| 6 | Rear Handle & Support Spring | TW501.2248X |
| 7 | Rear Connector Nut | TW500.0213X |
| 8 | Euro Central Connector KZ-2 | TW501.0003 |
| 9 | Liner Positioner Nut M10x1 | TW501.0082 |
