esab psf 315
Tonyweld
315A Mig Welding Torch Easb Type PSF315 Co2 Gas Air Cooled Gun with Euro Connector
315A Mig Welding Torch Easb Type PSF315 Co2 Gas Air Cooled Gun with Euro Connector
| 315A Mig Welding Torch Easb Type PSF315 Co2 Gas Air Cooled Gun with Euro Connector Technical Data |
| TWPSF315 AIR COOLED MIG WELDING TORCH | ||
| Technical Data： | Rating : 315A CO2/285A Mixed Gases | |
| Duty Cycle : 60% | ||
| Wire Size : 0.8-1.2mm | ||
| No. | Description | Order |
| TWPSF315 Air Cooled Welding Torch 3m | TW0700 025 030 | |
| TWPSF315 Air Cooled Welding Torch 4m | TW0700 025 031 | |
| TWPSF315 Air Cooled Welding Torch 5m | TW0700 025 032 | |
| A | Nozzle Ф 16mm | TW0458 464 882 |
| A-1 | Nozzle Insulation Bushing | TW0458 471 003 |
| B | Contact Tip M6*27*0.8mm | TW0468 500 003 |
| Contact Tip M6*27*0.9mm | TW0468 500 004 | |
| Contact Tip M6*27*1.0mm | TW0468 500 005 | |
| Contact Tip M6*27*1.2mm | TW0468 500 006 | |
| Contact Tip M6*27*1.4mm | TW0468 500 008 | |
| Contact Tip M6*27*1.6mm | TW0468 500 009 | |
| C | Tip Adapter M6 | TW0366 394 001 |
| D | Liner Steel insulation Red Wire φ 1.0-1.2mm 3m | TW0700 200 087 |
| Liner Steel insulation Red Wire φ 1.0-1.2mm 4m | TW0700 200 088 | |
| Liner Steel insulation Red Wire φ 1.0-1.2mm 5m | TW0700 025 801 | |
| 1 | TWPSF315 Swan Neck | TW0700 025 001 |
| 2 | Handle Expert Plus | TW0700 025 905 |
| 3 | Switch | TW0700 025 903 |
| 4 | Switch Long | TW0800 025 903 |
| 5 | Cable Ball Joint & Support Spring | TW0700 025 90G |
| 6 | Cable Assembly 3m | TW0700 025 964 |
| Cable Assembly 4m | TW0700 025 965 | |
| Cable Assembly 5m | TW0700 025 966 | |
| 7 | Support Spring | TW0700 020 907 |
| 8 | Rear Handle | TW0700 025 907 |
| 9 | Adaptor Nut M33x2 | TW0700 025 951 |
| 10 | Euro Central Connector | TW0700 200 101 |
| 11 | Liner Positioner Nut M10x1 | TW0700 200 098 |
| Mig Welding Torch Esab Series Related Products |
| TW0700 025 020 TWPSF 260 Welding torch 3m |
| TW0700 025 021 TWPSF 260 Welding torch 4m |
| TW0700 025 022 TWPSF 260 Welding torch 5m |
| TW0700 025 030 TWPSF 315 Welding torch 3m |
| TW0700 025 031 TWPSF 315 Welding torch 4m |
| TW0700 025 032 TWPSF 315 Welding torch 5m |
| TW0700 025 040 TWPSF 415 Welding torch 3m |
| TW0700 025 041 TWPSF 415 Welding torch 4m |
| TW0700 025 042 TWPSF 415 Welding torch 5m |
| TW0700 025 050 TWPSF 515 Welding torch 3m 50mm² |
| TW0700 025 051 TWPSF 515 Welding torch 4m 50mm² |
| TW0700 025 052 TWPSF 515 Welding torch 5m 50mm² |
| TW0700 025 050 TWPSF 515 Welding torch 3m 56mm² |
| TW0700 025 051 TWPSF 515 Welding torch 4m 56mm² |
| TW0700 025 052 TWPSF 515 Welding torch 5m 56mm² |
| TW0700 025 060 TWPSF 420W Water Welding torch 3m |
| TW0700 025 061 TWPSF 420W Water Welding torch 4m |
| TW0700 025 062 TWPSF 420W Water Welding torch 5m |
| TW0700 025 070 TWPSF 520W Water Welding torch 3m |
| TW0700 025 071 TWPSF 520W Water Welding torch 4m |
| TW0700 025 072 TWPSF 520W Water Welding torch 5m |
