Product Category

Brazil OXIMIG SBME 350 gas air cooled CO2 Mig welding torches 3/4/5 M

Share to:

Brazil OXIMIG SBME 350 gas air cooled CO2 Mig welding torches 3/4/5 M Technical Data： Rating : 360A CO2/320A Mixed Gases Duty Cycle : 60% Wire Size : 0.8-1.6MM

规格:	OXIMIG SBME 350 air cooled CO2 Mig welding torch
Quantity:



Inquire Add to Basket

Model:
Brazil OXIMIG SBME 350
Brand:
Tonyweld
Code:
85159000
Product Name :
OXIMIG SBME 350 air cooled CO2 Mig welding torch
series :
OXIMIG SBME 350
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
360A CO2/320A Mixed Gases
Duty Cycle :
60%
connector :
euro / miller /bernard connector and etc
wire size :
0.8-1.6MM

Product Description

Brazil OXIMIG SBME 350 air cooled CO2 Mig welding torch And Mig consumables
OXIMIG-7

Brazil OXIMIG SBME 350 air cooled CO2 Mig welding torch mig welding consumables

OXIMIG SBME350 Air Cooled MIG Welding Torch
Technical Data：	Rating : 360A CO2/320A Mixed Gases
	Duty Cycle : 60%
	Wire Size : 0.8-1.6MM

No.	Description	Order
	SBME350 Welding Torch 3m	TWMW133
	SBME350 Welding Torch 4m	TWMW134
	SBME350 Welding Torch 5m	TWMW135

A	Nozzle ф16*75mm	TWME518*
	Nozzle ф18*75mm	TWME524
B	Contact Tip E-CU M8380.8mm	TWMA030
	Contact Tip E-CU M8380.9mm	TWMA031
	Contact Tip E-CU M8381.0mm	TWMA032
	Contact Tip E-CU M8381.2mm	TWMA033*
	Contact Tip E-CU M8381.6mm	TWMA034
B-1	Contact Tips M8 30mm
C	Tip Holder M8*40mm	TWMB403*
C-1	Tip Holder Long M8*48mm	TWMB414
D	Insulator	TWMC442*
E	Red Steel Liner Wire 1.0-1.2mm 3m	TWMP803
	Red Steel Liner Wire 1.0-1.2mm 4m	TWMP804
	Red Steel Liner Wire 1.0-1.2mm 5m	TWMP805

No.	Description	Order
1	SBME350 Swan neck	TWMF575
1-1	Swan Neck Holder	TWMG623
2	Front Handle	TWMG620
3	Switch	TWMJ680
4	Spring Button	TWMK690
5	Switch Button	TWML710
6	Cable Ball Joint & Sapport Spring	TWMK704
7	Power Cable 35mm²
8	Support Spring	TWMK709
9	Rear Handle	TWMR883
10	Adaptor Nut M33x2	TWMK690
11	Euro Central Connector	TWMO770
12	Liner Positioner Nut M10x1	TWMN762

Brazil OXIMIG SBME 350 air cooled CO2 Mig welding torch package

* 1 piece Brazil OXIMIG SBME 235 air cooled CO2 Mig welding torch package in a carton

Our Sevice

* timely online 24 hours .

* sample order /trail order is available .

*supply the qualified products.

*after -sale service

*processing customer's sample .
