| 规格: | |
|---|---|
| Quantity: | |
Brazil OXIMIG SBME125
Tonyweld
85159000
OXIMIG SBME 125 air cooled CO2 Mig welding torch
OXIMIG SBME 125
1piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
250A CO2/220A Mixed Gases
60%
euro / miller /bernard connector and etc
0.8-1.0MM
| OXIMIG SBME125 Air Cooled MIG Welding Torch | ||
| Technical Data： | Rating : 250A CO2/220A Mixed Gases | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-1.0MM | |
| | | |
| No. | Description | Order |
| | SBME125 Welding Torch 3m | TWMW113 |
| | SBME125 Welding Torch 4m | TWMW114 |
| | SBME125 Welding Torch 5m | TWMW115 |
| | | |
| A | Nozzle ф15*75mm | TWME511* |
| | Nozzle ф12*75mm | TWME536 |
| B | Contact Tip E-CU M6*37*0.8mm OD.8mm | TWMA020 |
| | Contact Tip E-CU M6*37*0.9mm OD.8mm | TWMA021 |
| | Contact Tip E-CU M6*37*1.0mm OD.8mm | TWMA022* |
| | Contact Tip E-CU M6*37*1.2mm OD.8mm | TWMA023 |
| C | Tip Holder M6*37.2mm | TWMB401* |
| D | Insulator | TWMC440* |
| E | Blue Steel Liner Wire 0.8-1.0mm 3m | TWMP800 |
| | Blue Steel Liner Wire 0.8-1.0mm 4m | TWMP801 |
| | Blue Steel Liner Wire 0.8-1.0mm 5m | TWMP802 |
| | | |
| No. | Description | Order |
| 1 | SBME116/125 Swan Neck | TWMF571* |
| 2 | Front Handle | TWMG620 |
| 3 | Switch | TWMJ680 |
| 4 | Spring Button | TWMK690 |
| 5 | Switch Button | TWML710 |
| 6 | Cable Ball Joint & Support Spring | TWMK704 |
| 7 | Power Cable 25mm2 | |
| 8 | Support Spring | TWMK709 |
| 9 | Rear Handle | TWMR883 |
| 10 | Adaptor Nut M33x2 | TWMK690 |
| 11 | Euro Central Connector | TWMO770 |
| 12 | Liner Positioner Nut M10x1 | TWMN762 |
| OXIMIG SBME125 Air Cooled MIG Welding Torch | ||
| Technical Data： | Rating : 250A CO2/220A Mixed Gases | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-1.0MM | |
| | | |
| No. | Description | Order |
| | SBME125 Welding Torch 3m | TWMW113 |
| | SBME125 Welding Torch 4m | TWMW114 |
| | SBME125 Welding Torch 5m | TWMW115 |
| | | |
| A | Nozzle ф15*75mm | TWME511* |
| | Nozzle ф12*75mm | TWME536 |
| B | Contact Tip E-CU M6*37*0.8mm OD.8mm | TWMA020 |
| | Contact Tip E-CU M6*37*0.9mm OD.8mm | TWMA021 |
| | Contact Tip E-CU M6*37*1.0mm OD.8mm | TWMA022* |
| | Contact Tip E-CU M6*37*1.2mm OD.8mm | TWMA023 |
| C | Tip Holder M6*37.2mm | TWMB401* |
| D | Insulator | TWMC440* |
| E | Blue Steel Liner Wire 0.8-1.0mm 3m | TWMP800 |
| | Blue Steel Liner Wire 0.8-1.0mm 4m | TWMP801 |
| | Blue Steel Liner Wire 0.8-1.0mm 5m | TWMP802 |
| | | |
| No. | Description | Order |
| 1 | SBME116/125 Swan Neck | TWMF571* |
| 2 | Front Handle | TWMG620 |
| 3 | Switch | TWMJ680 |
| 4 | Spring Button | TWMK690 |
| 5 | Switch Button | TWML710 |
| 6 | Cable Ball Joint & Support Spring | TWMK704 |
| 7 | Power Cable 25mm2 | |
| 8 | Support Spring | TWMK709 |
| 9 | Rear Handle | TWMR883 |
| 10 | Adaptor Nut M33x2 | TWMK690 |
| 11 | Euro Central Connector | TWMO770 |
| 12 | Liner Positioner Nut M10x1 | TWMN762 |
