Brazil OXIMIG SBME 235 gas air cooled CO2 Mig welding torches 3/4/5 M

Share to:

Brazil OXIMIG SBME 235 gas air cooled CO2 Mig welding torches 3/4/5 M Technical Data： Rating : 300A CO2/260A Mixed Gases Duty Cycle : 60% Wire Size : 0.8-1.2MM

规格:	OXIMIG SBME 235 air cooled CO2 Mig welding torch
Quantity:



Inquire Add to Basket

Model:
Brazil OXIMIG SBME 235
Brand:
Tonyweld
Code:
85159000
Product Name :
OXIMIG SBME 235 air cooled CO2 Mig welding torch
series :
OXIMIG SBME 235
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
300A CO2/260A Mixed Gases
Duty Cycle :
60%
connector :
euro / miller /bernard connector and etc
wire size :
0.8-1.2MM

Product Description

Brazil OXIMIG SBME 235 air cooled CO2 Mig welding torch And Mig consumables
OXIMIG-6

Brazil OXIMIG SBME 235 air cooled CO2 Mig welding torch mig welding consumables

OXIMIG SBME235 Air Cooled MIG Welding Torch
Technical Data：	Rating : 300A CO2/260A Mixed Gases
	Duty Cycle : 60%
	Wire Size : 0.8-1.2MM

No.	Description	Order
	SBME235 Welding Torch 3m	TWMW223
	SBME235 Welding Torch 4m	TWMW224
	SBME235 Welding Torch 5m	TWMW225

A	Nozzle ф15*35mm	TWME514*
	Nozzle ф19*35mm	TWME521
A-1	Nozzle ф15*66mm	TWME616
A-2	Nozzle ф12*66mm	TWME618
B	Nozzle Holder Short L:50mm	TWMD490*
C	Contact Tip W5/16550.8mm	TWMA050
	Contact Tip W5/16550.9mm	TWMA051
	Contact Tip W5/16551.0mm	TWMA052
	Contact Tip W5/16551.2mm	TWMA053*
	Contact Tip W5/16551.6mm	TWMA054
	Contact Tip W5/16552.4mm	TWMA055
C-1	Contact Tip W5/16430.8mm	TWMA280
	Contact Tip W5/16430.9mm	TWMA281
	Contact Tip W5/16431.0mm	TWMA282
	Contact Tip W5/16431.2mm	TWMA283
	Contact Tip W5/16431.6mm	TWMA284
C-2	Contact Tip Rebaixado W5/16430.8mm	TWMA286
	Contact Tip Rebaixado W5/16430.9mm	TWMA287
	Contact Tip Rebaixado W5/16431.0mm	TWMA288
	Contact Tip Rebaixado W5/16431.2mm	TWMA289
D	Tip Holder S19*44mm	TWMB405*
D-1	Tip Holder S16*44mm	TWMB405S
E	Insulator	TWMC444*
F	Red Steel Liner Wire 1.0-1.2mm 3m	TWMP803
	Red Steel Liner Wire 1.0-1.2mm 4m	TWMP804
	Red Steel Liner Wire 1.0-1.2mm 5m	TWMP805

No.	Description	Order
1	SBME235 Swan neck	TWMF574*
2	Front Handle	TWMG755
3	Switch	TWMJ680
4	Spring Button	TWMK690
5	Switch Button	TWML710
6	Cable Ball Joint & Support Spring	TWMK704
7	Power Cable 35mm²
8	Support Spring	TWMK709
9	Rear Handle	TWMR883
10	Adaptor Nut M33x2	TWMK690
11	Euro Central Connector	TWMO770
12	Liner Positioner Nut M10x1	TWMN762

Brazil OXIMIG SBME 235 air cooled CO2 Mig welding torch package

* 1 piece Brazil OXIMIG SBME 235 air cooled CO2 Mig welding torch package in a carton
