规格: | |
---|---|
Quantity: | |
Fronius mtg250i air cooled mig welding torch 3.5M 4.5M
Tonyweld
85159000
Fronius mtg250i air cooled mig welding torch 3.5M
fronius
1piece a plastic box
3.5m 4.5m or according to customer request
Jiangsu, China (Mainland)
320A CO2/210A Mixed Gases
40%
fronius / euro connector
0.8-1.6mm
Fronius mtg 250i air cooled mig welding torch 3.5M | ||
Technical Data: | Rating : 320A CO2/210A Mixed Gases | |
| Duty Cycle : 40% | |
| connector : fronius / euro | |
| connector wire size : 0.8-1.6mm | |
| | |
No. | Description | Order |
| MTG 250i Gas Cooled Welding Torch FSC Connector 3.5m | TW4,035,921 |
| MTG 250i Gas Cooled Welding Torch FSC Connector 4.5m | TW4,035,924 |
| MTG 250i Gas Cooled Welding Torch Euro Connector 3.5m | TW4,035,921E |
| MTG 250i Gas Cooled Welding Torch Euro Connector 4.5m | TW4,035,924E |
| | |
A | Nozzle ф10*58mm | TW42,0001,4084 |
| Nozzle ф13*58mm Standard | TW42,0001,4065 |
| Nozzle ф15*58mm | TW42,0001,4493 |
| Nozzle ф18*58mm | TW42,0001,4055 |
B | Contact Tip E-Cu M6*24*0.6mm | TW42,0001,4928 |
| Contact Tip E-Cu M6*24*0.7mm | TW42,0001,6524 |
| Contact Tip E-Cu M6*24*0.8mm | TW42,0001,4461 |
| Contact Tip E- Cu M6*24*0.9mm | TW42,0001,4462 |
| Contact Tip E-Cu M6*24*1.0mm | TW42,0001,4463 |
| Contact Tip E-Cu M6*24*1 .2mm | TW42,0001,4464 |
| Contact Tip E-Cu M6*24*1.4mm | TW42,0001,4465 |
| Contact Tip E-Cu M6*24*1 .6mm | TW42,0001,4466 |
| Contact Tip E-Cu AL M6*24*0.8mm | TW42,0001,6525 |
| Contact Tip E-Cu AL M6*24*1.0mm | TW42,0001,6526 |
| Contact Tip E-Cu AL M6*24*1 .2mm | TW42,0001,6528 |
| Contact Tip E Cu AL M6*24*1.6mm | TW42,0001,6523 |
C | Gas Diffuser | TW42,0100,0552 |
C1 | Gas Diffuser HD | TW42,0100,0531 |
D | Contact Tip Holder | TW42,0001,3988 |
E | Insulator | TW42,0100,1428 |
E1 | Insulator HD | TW42,0100,0529 |
F | MTG/MTW Liner Steel 0.9-1.0mm 5m | TW40,0002,0041 |
| | |
No. | Description | Order |
1 | Swan Neck | TW44,0350,3240 |
2 | Front Handle | TW42,0405,0660 |
3 | Switch | TW43,0002,0386 |
4 | Cable Ball Joint & Support Spring Middle | TW400,1010M |
5 | Power Cable 3.5m | TW43,0004,4439 |
| Power Cable 4.5m | TW43,0004,4440 |
6 | Support Spring | TWFNSSS |
7 | Rear Handle | TWFNSRH |
8 | Rear Handle Connector | TWFNSRHC |
9 | MTG Gas Central Connector | TWFNSMTGCC |
10 | MTG/MTWLinerClamping Piece 0.9-1.0mmBlue Nut | TW44,0350,3317 |
Fronius mtg 250i air cooled mig welding torch 3.5M | ||
Technical Data: | Rating : 320A CO2/210A Mixed Gases | |
| Duty Cycle : 40% | |
| connector : fronius / euro | |
| connector wire size : 0.8-1.6mm | |
| | |
No. | Description | Order |
| MTG 250i Gas Cooled Welding Torch FSC Connector 3.5m | TW4,035,921 |
| MTG 250i Gas Cooled Welding Torch FSC Connector 4.5m | TW4,035,924 |
| MTG 250i Gas Cooled Welding Torch Euro Connector 3.5m | TW4,035,921E |
| MTG 250i Gas Cooled Welding Torch Euro Connector 4.5m | TW4,035,924E |
| | |
A | Nozzle ф10*58mm | TW42,0001,4084 |
| Nozzle ф13*58mm Standard | TW42,0001,4065 |
| Nozzle ф15*58mm | TW42,0001,4493 |
| Nozzle ф18*58mm | TW42,0001,4055 |
B | Contact Tip E-Cu M6*24*0.6mm | TW42,0001,4928 |
| Contact Tip E-Cu M6*24*0.7mm | TW42,0001,6524 |
| Contact Tip E-Cu M6*24*0.8mm | TW42,0001,4461 |
| Contact Tip E- Cu M6*24*0.9mm | TW42,0001,4462 |
| Contact Tip E-Cu M6*24*1.0mm | TW42,0001,4463 |
| Contact Tip E-Cu M6*24*1 .2mm | TW42,0001,4464 |
| Contact Tip E-Cu M6*24*1.4mm | TW42,0001,4465 |
| Contact Tip E-Cu M6*24*1 .6mm | TW42,0001,4466 |
| Contact Tip E-Cu AL M6*24*0.8mm | TW42,0001,6525 |
| Contact Tip E-Cu AL M6*24*1.0mm | TW42,0001,6526 |
| Contact Tip E-Cu AL M6*24*1 .2mm | TW42,0001,6528 |
| Contact Tip E Cu AL M6*24*1.6mm | TW42,0001,6523 |
C | Gas Diffuser | TW42,0100,0552 |
C1 | Gas Diffuser HD | TW42,0100,0531 |
D | Contact Tip Holder | TW42,0001,3988 |
E | Insulator | TW42,0100,1428 |
E1 | Insulator HD | TW42,0100,0529 |
F | MTG/MTW Liner Steel 0.9-1.0mm 5m | TW40,0002,0041 |
| | |
No. | Description | Order |
1 | Swan Neck | TW44,0350,3240 |
2 | Front Handle | TW42,0405,0660 |
3 | Switch | TW43,0002,0386 |
4 | Cable Ball Joint & Support Spring Middle | TW400,1010M |
5 | Power Cable 3.5m | TW43,0004,4439 |
| Power Cable 4.5m | TW43,0004,4440 |
6 | Support Spring | TWFNSSS |
7 | Rear Handle | TWFNSRH |
8 | Rear Handle Connector | TWFNSRHC |
9 | MTG Gas Central Connector | TWFNSMTGCC |
10 | MTG/MTWLinerClamping Piece 0.9-1.0mmBlue Nut | TW44,0350,3317 |
