Fronius mig welding torch air cooled AL 3000

Share to:

ALAL3000 Air cooled Welding Torch

Technical Data：
Rating: 300A CO2/250A Mixed Gases
Duty Cycle:40%
Wire Size:1.0-1.2mm

规格:	FRONIUS AL3000 WELDING TORCH
Quantity:



Inquire Add to Basket

Model:
Fronius AL3000
Brand:
Tonyweld
Code:
85159000
Product Name :
Fronius mig welding torch air cooled AL3000
series :
fronius
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
300A CO2/250A Mixed Gases
Duty Cycle :
40%
connector :
fronius / euro connector
wire size :
1.0-1.2mm

Product Description

Fronius mig welding torch air cooled AL 3000 euro connector

AL3000 Air cooled Welding Torch
Technical Data：	Rating: 300A CO2/250A Mixed Gases
	Duty Cycle:40%
	Wire Size:1.0-1.2mm
No.	Description	Order
	AL3000 3.5m Welding Torch Euro Connector	4.035.600.001
	AL3000 4.5m Welding Torch Euro Connector	4.035.601.001
	AL3000 3.5m Welding Torch Fronius Connector	4.035.600
	AL3000 4.5m Welding Torch Fronius Connector	4.035.601

A	Nozzle φ11*67mm	42.0001.5151
	Nozzle φ13*67mm	42.0001.5096
	Nozzle φ15*67mm	42.0001.5269
	Nozzle φ17*67mm	42.0001.5821
	Nozzle φ18*67mm	44.0350.2070
	Nozzle φ13*65mm	42.0001.5619
B	Contact Tip CuCrZr M8350.8mm	42.0001.2911
	Contact Tip CuCrZr M8350.9mm	42.0001.3082
	Contact Tip CuCrZr M8351.0mm	42.0001.2912
	Contact Tip CuCrZr M8351.2mm	42.0001.2913
	Contact Tip AL CuCrZr M8350.8mm	42.0001.5082
	Contact Tip AL CuCrZr M8351.0mm	42.0001.5051
	Contact Tip AL CuCrZr M8351.2mm	42.0001.5052
	Contact Tip AL CuCrZr M8351.4mm	42.0001.5053
	Contact Tip AL CuCrZr M8351.6mm	42.0001.3485
C	Contact Tip Holder	42.0001.5084
D	Insulator	42.0100.1014
E	Nozzle Retainer	42.0001.2930
F	Liner Steel 1.0mm 3.5m	42.0404.0273
	Liner Steel 1.0mm 4.5m	42.0404.0274
	Liner Steel 1.2mm 3.5m	42.0404.0275
	Liner Steel 1.2mm 4.5m	42.0404.0276

No.	Description	Order
1	Swan Neck 45°	34.0350.1771
2	Front Handle	42.0405.0660
3	Switch	43.0002.0386
4	Cable Ball Joint & Support Rubber	400.D574
5	Power Cable 3.5m	43.0004.1265
	Power Cable 4.5m	43.0004.1266
6	Rear Handle	42.0405.0655
7	Rear Connector Nut	42.0405.0560
8	Control Lead Plug	43.0004.1257
9	Central Connector	34.0350.1416
10	Liner Steel Positioner Nut 1.2mm	42.0001.1508
11	Liner Teflon Positioner Combi	42.0001.5412
11-1	Liner Teflon Positioner Nut	42.0400.1025

Fronius mig torch fronius connector

* 1 piece Fronius mig welding torch package in a carton
