Fronius mig welding torch AW 2500 Water Cooled Welding Torch

Share to:

AW 2500 Water Cooled Welding Torch

Technical Data：
Rating: 250A CO2/220A Mixed Gases
Duty Cycle:100%
Wire Size: 0.6-1.2mm

规格:	FRONIUS AL2500 WELDING TORCH
Quantity:



Inquire Add to Basket

Model:
Fronius AW 2500 Water Cooled Welding Torch
Brand:
Tonyweld
Code:
85159000
Product Name :
Fronius mig welding torch Rating: 250A CO2/220A
series :
fronius
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
250A CO2/220A Mixed Gases
Duty Cycle :
100%
connector :
fronius / euro connector
wire size :
1.0-1.2mm

Product Description

Fronius mig welding torch Fronius mig welding torch AW 2500 Water Cooled Welding Torch euro connector

AW 2500 Water Cooled Welding Torch
Technical Data：	Rating: 250A CO2/220A Mixed Gases
	Duty Cycle:100%
	Wire Size: 0.6-1.2mm
No.	Description	Order
	AW2500 3.5m Water Welding Torch Euro Connector	4.035.641.001
	AW2500 4.5m Water Welding Torch Euro Connector	4.035.642.001
	AW2500 3.5m Water Welding Torch Fronius Connector	4.035.641.000
	AW2500 4.5m Water Welding Torch Fronius Connector	4.035.642.000

A	Nozzle φ10*66mm	42.0001.5174
	Nozzle φ12*66mm	42.0001.5173
	Nozzle φ17*66mm	42.0001.5172
	Nozzle φ12*62.5mm	42.0001.6010
B	Contact Tip CuCrZr M6330.6mm	42.0001.0052
	Contact Tip CuCrZr M6330.8mm	42.0001.0053
	Contact Tip CuCrZr M6330.9mm	42.0001.3276
	Contact Tip CuCrZr M6331.0mm	42.0001.0054
	Contact Tip CuCrZr M6331.2mm	42.0001.0055
	Contact Tip CuCrZr M6331.4mm	42.0001.1929
	Contact Tip CuCrZr M6331.6mm	42.0001.0056
C	Contact Tip Holder	42.0001.1718
D	Insulator	42.0100.0225
E	Nozzle Retainer	42.0001.5171
F	Liner Steel 1.0mm 3.5m	42.0404.0244
	Liner Steel 1.0mm 4.5m	42.0404.0245
	Liner Steel 1.2mm 3.5m	42.0404.0174
	Liner Steel 1.2mm 4.5m	42.0404.0181

No.	Description	Order
1	Swan Neck 45°	34.0350.1876
2	Front Handle	42.0405.0660
3	Switch	43.0002.0386
4	Cable Ball Joint & Support Spring Water	500.0233
5	Gas Hose Red φ5*8 Units:100m	40.0001.0310
5-1	Hose Clamp φ8.7mm	42.0407.0284
6	Water Hose Blue φ5*8 Units:100m	40.0001.0310
6-1	Hose Clamp φ9.0mm	42.0407.0272
7	Wire Conduit 3.5m	44.0350.1818
	Wire Conduit 4.5m	44.0350.1819
8	Power Cable 3.5m	43.0004.0109
	Power Cable 4.5m	43.0004.0110
9	Control Cable 2-pole 3.5m	43.0004.1160
	Control Cable 2-pole 4.5m	43.0004.1161
9-1	Trigger Wire Connector	43.0003.0217
9-2	Trigger Wire Connector Control Lead Plug	43.0004.1257
10	Outer Cover φ25×1.5 3.5m	44.0350.1804
	Outer Cover φ25×1.5 4.5m	44.0350.1805
11	Water Outlet Hose Red φ5*8	40.0001.0310
12	Plug Nipple ND 5mm	42.0001.1506
13	Fastener Cap Red	42.0405.0548R
13-1	Fastener Cap Blue	42.0405.0548B
14	Rear Handle	42.0405.0655
15	Rear Connector Nut	42.0405.0560
16	Central Connector Water Cooled	34.0350.1190
17	Liner Steel Positioner Nut 1.0mm	42.0001.1743
18	Liner Teflon Positioner Combi	42.0001.5412
18-1	Liner Teflon Positioner Nut	42.0400.1025

Fronius mig torch fronius connector

* 1 piece Fronius mig welding torch package in a carton
