Product Category

Tre 500A Air Cooled MIG GUN CO2 mig welding torch and consumables

Tregaskiss 500A Air Cooled MIG GUN CO2 mig welding torch and consumables

Share to:

TRE 500A Air Cooled MIG GUN Technical Data： Rating: 500A CO2/400A Mixed Gases Duty Cycle: 60% Wire Size: .040”-3/32”(1.0–2.4mm)

Availability:

Quantity:



Inquire Add to Basket

Model:
TR500 Air Cooled MIG GUN4
Brand:
Tonyweld
Code:
85159000

Product Description

Tre 500A Air Cooled MIG GUN CO2 mig welding torch and consumables
Tregaskiss-8

TWTR500 Air Cooled MIG GUN Technical Data： Rate : 500ACO2/400A Mixed Gases Duty Cycle : 60% Wire Size : .030”-1/16”(0.8-1.6MM) Type 10ft(3.0m) 12ft(3.5m) 15ft(4.5m) TWTR500 "C" Handle MIG GUN Euro Connector TW5010CE TW5012CE TW5015CE TWTR500 "C" Handle MIG GUN Miller Connector TW5010CM TW5012CM TW5015CM TWTR500 "C" Handle MIG GUN Tweco Connector TW5010CT TW5012CT TW5015CT TWTR500 "C" Handle MIG GUN Lincoln Connector TW5010CL TW5012CL TW5015CL TWTR500 "T" Handle MIG GUN Euro Connector TW5010TE TW5012TE TW5015TE TWTR500 "T" Handle MIG GUN Miller Connector TW5010TM TW5012TM TW5015TM TWTR500 "T" Handle MIG GUN Tweco Connector TW5010TT TW5012TT TW5015TT TWTR500 "T" Handle MIG GUN Lincoln Connector TW5010TL TW5012TL TW5015TL
No.	Description	Order
A	Nozze 3/8” 9.5mm Flush Copper	TW401-4-38
	Nozzle 1/2” 12.7mm 1/8” Recess Copper	TW401-4-50*
	Nozzle 5/8” 15.9mm 1/4” Recess Copper	TW401-4-62
	Nozzle 3/4” 19mm 1/8” Recess Copper	TW401-4-75
	Nozzle 5/8” 15.9mm 1/8” Stick Out Brass	TW401-8-62
	Nozze 5/8” 15.9mm 1/4” Stick Out Copper	TW401-9-62
	Nozzle 1/2” 12.7mm 1/4” Stick Out Brass	TW401-44-50
	Nozzle 1/2” 12.7mm 1/8” Stick Out Brass	TW401-48-50
	Nozzle 1/2” 12.7mm 1/8” Recess Brass	TW401-42-50
	Nozzle 3/8” 9.5mm 1/16 Recess Brass	TW401-40-38
B	Contact Tip .230” 0.6mm	TW403-23
	Contact Tip .030” 0.8mm	TW403-30
	Contact Tip .035” 0.9mm	TW403-35
	Contact Tip .040” 1.0mm	TW403-40
	Contact Tip .045” 1.2mm	TW403-45*
	Contact Tip .052” 1.4mm	TW403-52
	Contact Tip 1/1 6” 1.6mm	TW403-116
C	Gas Diffuser (1/4-20Thd)	TW404*
D	Nozzle Retainer	TW402-3*
E	Neck Insulator	TW402-11*
F	Liner For .035”-.045” (0.9-1.2 mm) 10ft(3.0m)	TW415-35-10
	Liner For .035”-.045” (0.9-1.2 mm) 1 5ft(5.0m)	TW415-35-15*

No.	Description	Order
1	Goose Neck 45° TR500	TW505-45
	Goose Neck 60° TR500	TW505-60*
2	Goose Neck Flexible	TW405-FL
3	Goose Neck Locating Ring	TW407
4	”C” Series Straight Handle	TW1780086
5	Cable Ball Joint & Support Spring Big	TW400.1010B
6	Switch Button/Aluminum	TW411-2X
7	Switch	TW411-1
8	”T” Series Straight Handle & Spring	TW410
9	Trigger Housing	TW411-2
10	End Fitting TR400/500	TW408
11	Cone Nut TR400/500	TW509
12	Cable Assembly	TWTR500
13	Euro-Kwik Style Rear Connector
13-1	Rear Strain Relief Spring	TWP102213
13-2	Euro Rear Handle	TWP001075
13-3	Euro Nut	TW4861
13-4	Euro Connector Tregaskiss Style	TW5060T
14	Economical Model Style Rear Connector
14-1	Rear Handle TR Style	TWP001075TR
14-2	Miller Control Wire & Plug	TWMS354-DSM
14-3	Lincoln Control Wire & Plug	TW35SP-354
14-4	Tweco Control Wire & Socket	TWMS354-TAJ
14-5	”Lincoln Control Jumper Cord”	TWMS354DS-LJ
15	Original Style Rear Connector
15-1	Control Housing With Screws	TW416-5
15-2	Miller Control Wire Direct Plug	TW419
15-3	Lincoln Control Wire Direct Plug	TWLAK-354
15-4	Tweco Control Wire Direct Plug & Socket	TWSCT1N
16	Power Pin Block	TW414-400
17	Tweco 4# Central Connector	TW214/2200103
	Tweco 5# Central Connector	TW214-12
18	Miller Central Connector	TW214-1/2200137
19	Power Pin Tip	TW214-116
20	Power Pin Insulator Tweco/Miller	TW414-400-20
21	Lincoln Central Connector	TW214-2/2200099
22	Power Pin Insulator Lincoln	TW414-400-14
23	Gas Hose With Clamp	TWGLM1

Tregaskiss 500A CO2 mig welding torch package

* 1 piece Bnd mig torch 200A package in a carton

Our Sevice

* timely online 24 hours .

* sample order /trail order is available .

*supply the qualified products.

*after -sale service

*processing customer's sample .
