Tre 400A Air Cooled MIG GUN CO2 mig welding torch and consumables

Tregaskiss 400A Air Cooled MIG GUN CO2 mig welding torch and consumables

Share to:

TRE 400A Air Cooled MIG GUN Technical Data： Rating: 400A CO2/350A Mixed Gases Duty Cycle: 60% Wire Size: .040”-1/16”(1.0-1.6mm)

Availability:

Quantity:



Inquire Add to Basket

Model:
TR300 Air Cooled MIG GUN4
Brand:
Tonyweld
Code:
85159000

Product Description

Tre 400A Air Cooled MIG GUN CO2 mig welding torch and consumables

Tregaskiss-6

TWTR400 Air Cooled MIG GUN Technical Data： Rate : 400ACO2/300A Mixed Gases Duty Cycle : 60% Wire Size : .030”-1/16”(0.8-1.6MM) Type 10ft(3.0m) 12ft(3.5m) 15ft(4.5m) TWTR400 ”C” Handle MIG GUN Euro Connector TW4010CE TW4012CE TW4015CE TWTR400 ”C” Handle MIG GUN Miller Connector TW4010CM TW4012CM TW4015CM TWTR400 ”C” Handle MIG GUN Tweco Connector TW4010CT TW4012CT TW4015CT TWTR400 ”C” Handle MIG GUN Lincoln Connector TW4010CL TW4012CL TW4015CL TWDR400 ”T” Handle MIG GUN Euro Connector TW4010TE TW4012TE TW4015TE TWTR400 ”T” Handle MIG GUN Miller Connector TW4010TM TW4012TM TW4015TM TWTR400 ”T” Handle MIG GUN Tweco Connector TW4010TT TW4012TT TW4015TT TWTR400 ”T” Handle MIG GUN Lincoln Connector TW4010TL TW4012TL TW4015TL
No.	Description	Order
A	Nozzle 3/8” 9.5mm Flush Copper	TW401-4-38
	Nozzle 1/2” 12.7mm 1/8” Recess Copper	TW401-4-50*
	Nozzle 5/8” 15.9mm 1/4”Recess Copper	TW401-4-62
	Nozzle 3/4” 19mm 1/8”Recess Copper	TW401-4-75
	Nozzle 5/8” 1 5.9mm 1/8” Stick Out Brass	TW401-8-62
	Nozzle 5/8” 15.9mm 1/4” Stick Out Copper	TW401-9-62
	Nozzle 1/2” 12.7mm 1/4” Stick Out Brass	TW401-44-50
	Nozzle 1/2” 12.7mm 1/8” Stick Out Brass	TW401-48-50
	Nozzle 1/2” 12.7mm 1/8” Recess Brass	TW401-42-50
	Nozzle 3/8” 9.5mm 1/16” Recess Brass	TW401-40-38
B	Contact Tip .230” 0.6mm	TW403-23
	Contact Tip .030” 0.8mm	TW403-30
	Contact Tip .035” 0.9mm	TW403-35
	Contact Tip .040” 1.0mm	TW403-40
	Contact Tip .045” 1.2mm	TW403-45*
	Contact Tip .052” 1.4mm	TW403-52
	Contact Tip 1/16” 1.6mm	TW403-116
C	Gas Diffuser (1/4-20Thd)	TW404*
D	Nozzle Retainer	TW402-3*
E	Neck Insulator	TW402-11 *
F	Liner For .035”-.045” (0.9-1.2 mm) 10f(3.0m)	TW415-35-10
	Liner For .035”-.045” (0.9-1.2 mm) 1 5ft(5.0m)	TW415-35-15*

No.	Description	Order
1	Goose Neck 45° TR400	TW405-45
	Goose Neck 60° TR400	TW405-60*
2	Goose Neck Flexible	TW405-FL
3	Goose Neck Locating Ring	TW407
4	”C” Series Straight Handle	TW1780086
5	Cable Ball Joint & Support Spring Big	TW400.1010B
6	Switch Button/Aluminum .	TW411-2X
7	Switch	TW411-1
8	”T” Series Straight Handle & Spring	TW410
9	Trigger Housing	TW411-2
10	End Fitting TR400/500	TW408
11	Cone Nut TR400/500	TW509
12	Cable Assembly	TWTR400
13	Euro-Kwik Style Rear Connector
13-1	Rear Strain Relief Spring	TWP102213
13-2	Euro Rear Handle	TWP001075
13-3	Euro Nut	TW4861
13-4	Euro Connector Tregaskiss Style	TW5060T
14	Economical Model Style Rear Connector
14-1	Rear Handle TR Style	TWP001075TR
14-2	Miller Control Wire & Plug	TWMS354-DSM
14-3	Lincoln Control Wire & Plug	TW35SP-354
14-4	Tweco Control Wire & Socket	TWMS354-TAJ
14-5	”Lincoln Control Jumper Cord”	TWMS354DS-LJ
15	Original Style Rear Connector
15-1	Control Housing With Screws	TW416-5
15-2	Miller Control Wire Direct Plug	TW419
15-3	Lincoln Control Wire Direct Plug	TWLAK-354
15-4	Tweco Control Wire Direct Plug & Socket	TWSCT1N
16	Power Pin Block	TW414-400
17	Tweco 4# Central Connector	TW214/2200103
	Tweco 5# Central Connector	TW214-12
18	Miller Central Connector	TW214-1/2200137
19	Power Pin Tip	TW214-116
20	Power Pin Insulator Tweco/Miller	TW414-400-20
21	Lincoln Central Connector	TW214-2/2200099
22	Power Pin Insulator Lincoln	TW414-400-14
23	Gas Hose With Clamp	TWGLM1

Tregaskiss 400A CO2 mig welding torch package

* 1 piece Bnd mig torch 200A package in a carton
