| 规格: | |
|---|---|
| Quantity: | |
Su Mig 535
Tonyweld
su535
SU Mig 535 AIR COOLED MIG WELDING TORCH
su mig
1 piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
380A CO2/350A Mixed Gases
fronius / euro connector
60%
0.8-1.6MM
| SU535 AIR COOLED MIG WELDING TORCH | ||
| Technical Data： | Rating : 380A CO2/350A Mixed Gases | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-1.6MM | |
| | | |
| No. | Description | Order |
| | TWSU535 3.0m Welding Torch | TW0500.5085 |
| | TWSU535 4.0m Welding Torch | TW0500.5086 |
| | TWSU535 5.0m Welding Torch | TW0500.5106 |
| | | |
| A | Nozzle ф16*96 | TW0500.2778 |
| | Nozzle ф19*96 | TW0500.2779 |
| A-1 | Nozzle W/Fast Coupling ф16*96 | TW0500.2914 |
| | Nozzle W/Fast Coupling ф19*96 | TW0500.2913 |
| B | Contact Tip W5/16*43*0.8mm | TW0500.1080 |
| | Contact Tip W5/1 6*43*1.0mm | TW0500.1081 |
| | Contact Tip W5/16*43*1.2mm | TW0500.1082 |
| | Contact Tip W5/16*43*1.6mm | TW0500.1083 |
| | Contact Tip W5/16*43*2.0mm | TW0500.1757 |
| | Contact Tip W5/16*43*2.4mm | TW0500.1492 |
| | Contact Tip CuCrZr W5/16*43*0.8mm | TW0500.1909 |
| | Contact Tip CuCrZr W5/16*43*1.0mm | TW0500.1910 |
| | Contact Tip CuCrZr W5/16*43*1.2mm | TW0500.1911 |
| B-1 | Contact Tip E-Cu W5/16*72.5*0.8mm | TW0500.1085 |
| | Contact Tip E-Cu W5/16*72.5*0.9mm | TW0500.1242 |
| | Contact Tip E-Cu W5/16*72.5*1.0mm | TW0500.1086 |
| | Contact Tip E-Cu W5/16*72.5*1.2mm | TW0500.1087 |
| | Contact Tip E-Cu W5/16*72.5*1.6mm | TW0500.1088 |
| B-2 | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*0.8mm | TW0900.1370 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*0.9mm | TW0900.1870 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.0mm | TW0900.1371 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.2mm | TW0900.1316 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.4mm | TW0900.1427 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.6mm | TW0900.1372 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*0.8mm | TW0900.1827 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*0.9mm | TW0900.1828 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.0mm | TW0900.1829 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.2mm | TW0900.1754 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.6mm | TW0900.1830 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*2.4mm | TW0900.1493 |
| C | Gas Diffuser W5/16*68mm | TW0500.2472 |
| C-1 | Gas Diffuser W/Fast Coupling W5/16*35mm | TW0500.1102 |
| C-2 | Gas Diffuser S+M8 Heavy Duty 81.7mm | TW0500.2997 |
| D | Gas Diffuser Insulator | TW0500.1103 |
| E | Blue Steel Liner Wire ф1.2-1.6 for 3m | TW0500.1118 |
| | Blue Steel Liner Wire ф1.2-1.6 for 4m | TW0500.1119 |
| | Blue Steel Liner Wire ф1.2-1.6 for 5m | TW0500.1245 |
| | | |
| No. | Description | Order |
| 1 | TWSU535 Torch Body 50° | TW0500.1104 |
| 2 | Front Handle | TWSU |
| 3 | Switch | TW185.0031L |
| 4 | Cable Ball Joint & Support Spring Middle | TW400.1010M |
| 5 | Power Cable 3m 4m 5m | |
| 6 | Rear Handle | TW700P001010 |
| 7 | Rear Handle Support Spring | TW600P102213 |
| 8 | Rear Connector Nut | TW700P002161 |
| 9 | Euro Central Connector | TW0500.2727 |
| 10 | Steel Liner Nut | TW0500.2603 |
| SU535 AIR COOLED MIG WELDING TORCH | ||
| Technical Data： | Rating : 380A CO2/350A Mixed Gases | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-1.6MM | |
| | | |
| No. | Description | Order |
| | TWSU535 3.0m Welding Torch | TW0500.5085 |
| | TWSU535 4.0m Welding Torch | TW0500.5086 |
| | TWSU535 5.0m Welding Torch | TW0500.5106 |
| | | |
| A | Nozzle ф16*96 | TW0500.2778 |
| | Nozzle ф19*96 | TW0500.2779 |
| A-1 | Nozzle W/Fast Coupling ф16*96 | TW0500.2914 |
| | Nozzle W/Fast Coupling ф19*96 | TW0500.2913 |
| B | Contact Tip W5/16*43*0.8mm | TW0500.1080 |
| | Contact Tip W5/1 6*43*1.0mm | TW0500.1081 |
| | Contact Tip W5/16*43*1.2mm | TW0500.1082 |
| | Contact Tip W5/16*43*1.6mm | TW0500.1083 |
| | Contact Tip W5/16*43*2.0mm | TW0500.1757 |
| | Contact Tip W5/16*43*2.4mm | TW0500.1492 |
| | Contact Tip CuCrZr W5/16*43*0.8mm | TW0500.1909 |
| | Contact Tip CuCrZr W5/16*43*1.0mm | TW0500.1910 |
| | Contact Tip CuCrZr W5/16*43*1.2mm | TW0500.1911 |
| B-1 | Contact Tip E-Cu W5/16*72.5*0.8mm | TW0500.1085 |
| | Contact Tip E-Cu W5/16*72.5*0.9mm | TW0500.1242 |
| | Contact Tip E-Cu W5/16*72.5*1.0mm | TW0500.1086 |
| | Contact Tip E-Cu W5/16*72.5*1.2mm | TW0500.1087 |
| | Contact Tip E-Cu W5/16*72.5*1.6mm | TW0500.1088 |
| B-2 | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*0.8mm | TW0900.1370 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*0.9mm | TW0900.1870 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.0mm | TW0900.1371 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.2mm | TW0900.1316 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.4mm | TW0900.1427 |
| | Contact tip E-Cu S+M8 Heavy Duty M8*30.5*1.6mm | TW0900.1372 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*0.8mm | TW0900.1827 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*0.9mm | TW0900.1828 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.0mm | TW0900.1829 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.2mm | TW0900.1754 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*1.6mm | TW0900.1830 |
| | Contact tip CuCrZr S+M8 Heavy Duty M8*30.5*2.4mm | TW0900.1493 |
| C | Gas Diffuser W5/16*68mm | TW0500.2472 |
| C-1 | Gas Diffuser W/Fast Coupling W5/16*35mm | TW0500.1102 |
| C-2 | Gas Diffuser S+M8 Heavy Duty 81.7mm | TW0500.2997 |
| D | Gas Diffuser Insulator | TW0500.1103 |
| E | Blue Steel Liner Wire ф1.2-1.6 for 3m | TW0500.1118 |
| | Blue Steel Liner Wire ф1.2-1.6 for 4m | TW0500.1119 |
| | Blue Steel Liner Wire ф1.2-1.6 for 5m | TW0500.1245 |
| | | |
| No. | Description | Order |
| 1 | TWSU535 Torch Body 50° | TW0500.1104 |
| 2 | Front Handle | TWSU |
| 3 | Switch | TW185.0031L |
| 4 | Cable Ball Joint & Support Spring Middle | TW400.1010M |
| 5 | Power Cable 3m 4m 5m | |
| 6 | Rear Handle | TW700P001010 |
| 7 | Rear Handle Support Spring | TW600P102213 |
| 8 | Rear Connector Nut | TW700P002161 |
| 9 | Euro Central Connector | TW0500.2727 |
| 10 | Steel Liner Nut | TW0500.2603 |
