| 规格: | |
|---|---|
| Quantity: | |
MAXI 450
Tonyweld
MAXI 450
MAXI 450 Gas Cooled Mig Welding Torch
maxi mig
1 piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
500A CO2/400A Mixed Gases
fronius / euro connector
60%
0.8-2.0MM
| MAXI 450 Gas Cooled Mig Welding Torch | ||
| Technical Data： | Rating : 500 CO2/400A Mixed Gas | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-2.0MM | |
| | | |
| No. | Description | Order |
| | TWMAXI450 3m Welding Torch | TWMA6465 |
| | TWMAXI450 4m Welding Torch | TWMA6466 |
| | TWMAXI450 5m Welding Torch | TWMA6467 |
| | | |
| A | Nozzle ф14*82mm | TWMC0298 |
| | Nozzle ф18*82mm | TWMC0012 |
| | Nozzle p20*82mm | TWMC0013 |
| B | Contact tip M8*30*1.0mm | TWMD0005-10 |
| | Contact tip M8*30*1.2mm | TWMD0005-12 |
| | Contact tip M8*30*1.4mm | TWMD0005-14 |
| | Contact tip M8*30*1.6mm | TWMD0005-16 |
| | Contact tip M8*30*2.0mm | TWMD0005-20 |
| | Contact tip M8*30*2.4mm | TWMD0005-24 |
| C | Tip Holder | TWME0006 |
| D | Insulator | TWMQ0186 |
| E | Steel Liner 1.2-1.6mm 3m | TWGM0013-3 |
| | Steel Liner 1.2-1.6mm 4m | TWGM0013-4 |
| | Steel Liner 1.2-1.6mm 5m | TWGM0013-5 |
| | | |
| No. | Description | Order |
| 1 | Swan Neck | TWMF0086 |
| 2 | Front Handle | TWMP0160 |
| 3 | Switch | TWBX0068 |
| 4 | Cable Assembly 3m | TWMH0249 |
| | Cable Assembly 4m | TWMH0250 |
| | Cable Assembly 5m | TWMH0251 |
| 5 | Cable Ball Joint & Support Spring Big | TW400.1010B |
| 6 | Rear Handle | TW501.2248 |
| 7 | Rear Connector Nut | TW500.0213L |
| 8 | Euro Central Connector | TWAR0083 |
| 9 | Liner Positioner Nut | TWFA0227 |
| MAXI 450 Gas Cooled Mig Welding Torch | ||
| Technical Data： | Rating : 500 CO2/400A Mixed Gas | |
| | Duty Cycle : 60% | |
| | Wire Size : 0.8-2.0MM | |
| | | |
| No. | Description | Order |
| | TWMAXI450 3m Welding Torch | TWMA6465 |
| | TWMAXI450 4m Welding Torch | TWMA6466 |
| | TWMAXI450 5m Welding Torch | TWMA6467 |
| | | |
| A | Nozzle ф14*82mm | TWMC0298 |
| | Nozzle ф18*82mm | TWMC0012 |
| | Nozzle p20*82mm | TWMC0013 |
| B | Contact tip M8*30*1.0mm | TWMD0005-10 |
| | Contact tip M8*30*1.2mm | TWMD0005-12 |
| | Contact tip M8*30*1.4mm | TWMD0005-14 |
| | Contact tip M8*30*1.6mm | TWMD0005-16 |
| | Contact tip M8*30*2.0mm | TWMD0005-20 |
| | Contact tip M8*30*2.4mm | TWMD0005-24 |
| C | Tip Holder | TWME0006 |
| D | Insulator | TWMQ0186 |
| E | Steel Liner 1.2-1.6mm 3m | TWGM0013-3 |
| | Steel Liner 1.2-1.6mm 4m | TWGM0013-4 |
| | Steel Liner 1.2-1.6mm 5m | TWGM0013-5 |
| | | |
| No. | Description | Order |
| 1 | Swan Neck | TWMF0086 |
| 2 | Front Handle | TWMP0160 |
| 3 | Switch | TWBX0068 |
| 4 | Cable Assembly 3m | TWMH0249 |
| | Cable Assembly 4m | TWMH0250 |
| | Cable Assembly 5m | TWMH0251 |
| 5 | Cable Ball Joint & Support Spring Big | TW400.1010B |
| 6 | Rear Handle | TW501.2248 |
| 7 | Rear Connector Nut | TW500.0213L |
| 8 | Euro Central Connector | TWAR0083 |
| 9 | Liner Positioner Nut | TWFA0227 |
