MAXI 4000
Tonyweld
MAXI 4000
MAXI 4000 Gas Cooled Mig Welding Torch
maxi mig
1 piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
500A CO2/450A Mixed Gases
fronius / euro connector
60%
1.0-2.4MM
| MAXI 4000 Gas Cooled Mig Welding Torch | ||
| Technical Data： | Rating : 500 CO2/450A Mixed Gas | |
| | Duty Cycle : 60% | |
| | Wire Size : 1.0-2.4MM | |
| | | |
| No. | Description | Order |
| | TWMAXI4000 3m Water Welding Torch | TW2343 |
| | TWMAXI4000 4m Water Welding Torch | TW2344 |
| | TWMAXI4000 5m Water Welding Torch | TW2345 |
| | | |
| A | Nozzle ф14*82mm | TWMC0298 |
| | Nozzle ф18*82mm | TWMC0012 |
| | Nozzle ф20*82mm | TWMC0013 |
| B | Contact tip M8*30*1.0mm | TWMD0005-10 |
| | Contact tip M8*30*1.2mm | TWMD0005-12 |
| | Contact tip M8*30*1.4mm | TWMD0005-14 |
| | Contact tip M8*30*1.6mm | TWMD0005-16 |
| | Contact tip M8*30*2.0mm | TWMD0005-20 |
| | Contact tip M8*30*2.4mm | TWMD0005-24 |
| C | Tip Holder | TWME0009 |
| E | SteelLiner 1.2-1.6mm 3m | TWGM0540 |
| | Steel Liner 1.2-1.6mm 4m | TWGM0541 |
| | Steel Liner 1.2-1.6mm 5m | TWGM0542 |
| | | |
| No. | Description | Order |
| 1 | Swan Neck | TWMG0016 |
| 2 | Swan Neck Holder | TWMT0072 |
| 3 | Front Handle | TWMP0160 |
| 4 | Switch | TWBX0068 |
| 5 | Cable Ball Joint & Support Spring Water | TW500.0233 |
| 6 | Water Hose Blue ф5*8 Units:1 00m | TWQB007X |
| 6-1 | Hose Clamp ф9.0mm | TWEA0282 |
| 7 | Wire/Gas Conduit 3m | TWQB0090 |
| | Wire/Gas Conduit 4m | TWQB0091 |
| | Wire/Gas Conduit 5m | TWQB0092 |
| 8 | Power Cable 3m . | TWQA0019 |
| | Power Cable 4m | TWQA0020 |
| | Power Cable 5m | TWQA0021 |
| 9 | Control Cable 2-pole Units:200m | TWBX015X |
| 10 | Outer Cover ф25x1.5 Units:20m | TWMQ020X |
| 11 | Water Outlet Hose Red ф5*8 With Plug Nipple | TWMH0272 |
| 12 | Plug Nipple ND 5mm | TWFA3020 |
| 13 | Fastener Cap Red | TW501.2423 |
| 13-1 | Fastener Cap Blue | TW501.2424 |
| 14 | Rear Handle Water | TWBW0328 |
| 15 | Adaptor Nut M33x2 | TWBW0480 |
| 16 | Water Central Adaptor | TWAR0102 |
| 17 | Liner Positioner Nut M10x1 | TWFA0026 |
| MAXI 4000 Gas Cooled Mig Welding Torch | ||
| Technical Data： | Rating : 500 CO2/450A Mixed Gas | |
| | Duty Cycle : 60% | |
| | Wire Size : 1.0-2.4MM | |
| | | |
| No. | Description | Order |
| | TWMAXI4000 3m Water Welding Torch | TW2343 |
| | TWMAXI4000 4m Water Welding Torch | TW2344 |
| | TWMAXI4000 5m Water Welding Torch | TW2345 |
| | | |
| A | Nozzle ф14*82mm | TWMC0298 |
| | Nozzle ф18*82mm | TWMC0012 |
| | Nozzle ф20*82mm | TWMC0013 |
| B | Contact tip M8*30*1.0mm | TWMD0005-10 |
| | Contact tip M8*30*1.2mm | TWMD0005-12 |
| | Contact tip M8*30*1.4mm | TWMD0005-14 |
| | Contact tip M8*30*1.6mm | TWMD0005-16 |
| | Contact tip M8*30*2.0mm | TWMD0005-20 |
| | Contact tip M8*30*2.4mm | TWMD0005-24 |
| C | Tip Holder | TWME0009 |
| E | SteelLiner 1.2-1.6mm 3m | TWGM0540 |
| | Steel Liner 1.2-1.6mm 4m | TWGM0541 |
| | Steel Liner 1.2-1.6mm 5m | TWGM0542 |
| | | |
| No. | Description | Order |
| 1 | Swan Neck | TWMG0016 |
| 2 | Swan Neck Holder | TWMT0072 |
| 3 | Front Handle | TWMP0160 |
| 4 | Switch | TWBX0068 |
| 5 | Cable Ball Joint & Support Spring Water | TW500.0233 |
| 6 | Water Hose Blue ф5*8 Units:1 00m | TWQB007X |
| 6-1 | Hose Clamp ф9.0mm | TWEA0282 |
| 7 | Wire/Gas Conduit 3m | TWQB0090 |
| | Wire/Gas Conduit 4m | TWQB0091 |
| | Wire/Gas Conduit 5m | TWQB0092 |
| 8 | Power Cable 3m . | TWQA0019 |
| | Power Cable 4m | TWQA0020 |
| | Power Cable 5m | TWQA0021 |
| 9 | Control Cable 2-pole Units:200m | TWBX015X |
| 10 | Outer Cover ф25x1.5 Units:20m | TWMQ020X |
| 11 | Water Outlet Hose Red ф5*8 With Plug Nipple | TWMH0272 |
| 12 | Plug Nipple ND 5mm | TWFA3020 |
| 13 | Fastener Cap Red | TW501.2423 |
| 13-1 | Fastener Cap Blue | TW501.2424 |
| 14 | Rear Handle Water | TWBW0328 |
| 15 | Adaptor Nut M33x2 | TWBW0480 |
| 16 | Water Central Adaptor | TWAR0102 |
| 17 | Liner Positioner Nut M10x1 | TWFA0026 |
