Lincoln Mig Welding Magnum 100L Gun FCAW 10FT 12FT 15FT

Share to:

LINCOLN MAGNUM 100L MIG WELDING TORCH Technical Data： Rating : 100A CO2 Duty Cycle : 40% Wire Size : .0.6 - 0.9 MM

规格:	MAGMU 100L
Quantity:



Inquire Add to Basket

Model:
Magnum 100L
Brand:
Tonyweld
Code:
K530-3
Product Name :
Lincoln Mig Welding Magnum 100L Gun FCAW 10FT 12FT
series :
Mig Welding torch
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
100A CO2
Duty Cycle :
40%
connector :
euro / mille /bnd connector and etc
wire size :
0.6-1.2mm

Product Description

Lincoln Magnum 100L mig welding torch and consumables

Lincoln-4

Lincoln Magnum 100L Gas Cooled Mig Welding Torch Gun
Technical Data：	Rating : 100A CO2
	Duty Cycle : 40%
	Wire Size : .025”-.035” (0.6-0.9MM)

No.	Description	Order
	TWMagnum 100L MIG GUN Spaded Lug Connector 10FT(3.0m)	K530-3
	TWMagnum 100L MIG GUN Spaded Lug Connector 10FT(3.0m)	K530-5
	TWMagnum 100L MIG GUN W4-PIN 10FT(3.0m)	K530-6

A	Nozzle Fixed Recessed 3/8”9.5mm	KP21-37
	Nozzle Fixed Recessed 1/2”12.7mm	KP21-50*
	Nozzle Fixed Recessed 5/8” 15.9mm	KP21-62
	Nozzle Fixed Flush 1/2”12.7mm	KP21-50F
A-1	Gasless Nozzle	KP1939-1*
B	Contact Tip .025” 0.6mm	KP11-25
	Contact Tip .030” 0.8mm	KP11-30
	Contact Tip .035” 0.9mm	KP11-35*
	Contact Tip .040” 1.0mm	KP11- 40
	Contact Tip .045” 1.2mm	KP11-45
	Contact Tip .025” 0.6mm Tapered	KP11T-25
	Contact Tip .030” 0.8mm Tapered	KP11T-30
	Contact Tip .035” 0.9mm Tapered	KP11T-35
	Contact Tip .040” 1.0mm Tapered	KP11T-40
	Contact Tip .045” 1.2mm Tapered	KP11T-45
	Contact Tip Aluminum .035” 0.9mm	KP2078-1B1
C	Gas Diffuser	KP35-50*
D	Liner for .025”-.035” (0.6-0.9mm) 15ft(4.6m)	KP35-40-15*
	Liner for .035”-.045” (0.9-1.2mm) 15ft(4.6m)	KP45- 40 -15
	Liner Aluminum for .035” (0.9mm) 15ft(4.6m)	KP1959-1

No.	Description	Order
1	TWMagnum 100L Gun Tube	KP2038-1*
2	Front Handle	9SG2209
3	Switch	9S1 85.0031S
4	Cable Assembly	9SM16318-1
5	Rear Handle Support Spring	9S285507
6	Rear Handle	9S285509
7	Connector Assembly	9SS20279
8	Control Wire & Plug	9SM16700
9	Control Wire & Cord Spaded Lug Connector	9SS19729

Lincoln Magnum 100L mig welding torch package

* 1 piece mig torch Magnum 100L package in a carton
