Lincoln Magnum 250L Gas Cooled Mig Welding Torch Gun

Share to:

Lincoln Magnum 250L Gas Cooled Mig Welding Torch Gun Technical Data： Rating : 250A CO2 Duty Cycle : 40% Wire Size : .025”-.045” (0.6-1.2MM)

规格:	Magnum 250L
Quantity:



Inquire Add to Basket

Model:
Magnum 250L
Brand:
Tonyweld
Code:
K533-3
Product Name :
CO2 Mig Welding Magnum 250L Torch 10FT 12FT 15FT
series :
Mig Welding torch
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
connector :
euro / mille /bnd connector and etc
Wire Size:
.0.6-1.2 MM

Product Description

Lincoln Magnum 250L mig welding torch and consumables

Lincoln-6

Lincoln Magnum 250L Gas Cooled Mig Welding Torch Gun
Technical Data：	Rating : 250A CO2
	Duty Cycle : 40%
	Wire Size : .025”-.045” (0.6-1.2MM)

No.	Description	Order
	TWMagnum 250L MIG Gun 12FT(3.5m)(Fixed Gas Nozzle)	TWK533-7
	TWMagnum 250L MIG Gun 15FT(4.5m)(Adjustable Gas Nozzle)	TWK533-3

A	Nozzle 3/8”9.5mm	TWKP22-37
	Nozzle 1/2”12.7mm	TWKP22-50*
	Nozzle 5/8” 15.9mm	TWKP22-62
B	Contact Tip .023” 0.6mm	TWKP14-25
	Contact Tip .030” 0.8mm	TWKP14-30
	Contact Tip .035” 0.9mm	TWKP14-35*
	Contact Tip .040” 1.0mm	TWKP14-40
	Contact Tip .045” 1.2mm	TWKP14-45
	Contact Tip .052” 1.3mm	TWKP14-52
	Contact Tip 1/16” 1.6mm	TWKP14-116
	Contact Tip 5/64” 2.0 mm	TWKP14-564
	Contact Tip AL 3/64” 1.2mm	TWKP14A-364
C	Slip on Nozzle Insulator Assembly	TWKP32*
D	Gas Diffuser Assembly (.035-.045)	TWKP52*
E	Liner for .025”-.030” (0.6-0.8mm) 15ft (4.6m)	TWKP42-25-15
	Liner for .030”-.035” (0.8-0.9mm) 15ft (4.6m)	TWKP42-3035-15
	Liner for .040”-.045” (1.0-1.2mm) 15ft (4.6m)	TWKP42- 4045-15*

No.	Description	Order
1	TWMagnum 250L Gun Tube 60° (Hard Cover)	TWKP2015-1
	TWMagnum 250L Gun Tube 60° (Rubber Cover)	TWKP2111-1*
2	Gun Handle (Left & Right)	TW9SG2217
3	Trigger Assembly	TW9SS21002
4	Spring Boot	TW9SS24676S
5	Cable Asbly
6	Rear Handle Support Spring	TW9S285507
7	Rear Handle	TW9S285509
8	Connector Assembly	TW9SS20280
9	Control Wire & Plug	TW9SM16700

Lin Magnum 250L mig welding torch package

* 1 piece mig torch Magnum 250L package in a carton

Our Sevice

* timely online 24 hours .

* sample order /trail order is available .

*supply the qualified products.

*after -sale service

*processing customer's sample .
