KEMPPI MMT/PMT35 Air Cooled MIG GUN and mig consumables

Share to:

MMT/PMT25 Air Cooled MIG GUN

Technical Data：
Rating: 350A Mixed Gases
Duty Cycle: 35 %
Wire Size: 0.8-1.6mm

规格:	KEMPPI MMT/PMT35 WHOEL TORCH
Quantity:



Inquire Add to Basket

Model:
KEMPPI MMT/PMT35
Brand:
Tonyweld
Code:
85159000
Product Name :
KEMPPI MMT/PMT35 Air Cooled MIG GUN and mig consu
series :
KEMPPI MMT/PMT25 torch 3
package :
1piece a plastic box
length :
3M or 4M or 5M or according to customer request
Place of Origin :
Jiangsu, China (Mainland)
Rating :
350A Mixed Gases
Duty Cycle :
35%
connector :
euro / miller /bernard connector and etc
wire size :
0.8-1.6mm

Product Description

KEMPPI MMT/PMT35 Air Cooled MIG GUN and mig consumables

MMT/PMT35 Air Cooled MIG GUN
Technical Data：	Rating: 350A CO2
	Duty Cycle:35 %
	Wire Size:0.8-1.6mm

No.	Description	Order
	MMT35 MIG GUN Air Cooled 3.0m	6253513MMT
	MMT35 MIG GUN Air Cooled 4.5m	6253514MMT
	PMT35 MIG GUN Air Cooled 3.0m	6253513
	PMT35 MIG GUN Air Cooled 4.5m	6253514

A	Nozzle With Insulating Ring φ16*77	4307050
	Nozzle Standard φ16*77	4300260
	Nozzle Long φ16*80	4300260L
	Nozzle Conical φ13*77	4300260C
A-1	Insulating Bush	4307020
B	Contact Tip M8 .030” 0.8mm	9580122
	Contact Tip M8 .035” 0.9mm	9580121
	Contact Tip M8 .039” 1.0mm	9580123
	Contact Tip M8 .045” 1.2mm	9580124
	Contact Tip M8 .052” 1.4mm	9580125
	Contact Tip M8 1/16” 1.6mm	9580126
	Contact Tip M8 5/64” 2.0mm	9580127
	Contact Tip M8 3/32” 2.4mm	9580128
C	Contact Tip Adapter M8	4295740
D	Gas Diffuser DMC	W004390
E	Wire Liner 0.9-1.2mm 3.0m/Red	4188581
	Wire Liner 0.9-1.2mm 4.5m/Red	4188582
	Wire Liner 0.9-1.2mm 3.5m/Red	W006453
	Wire Liner 0.9-1.2mm 5.0m/Red	W006454
E-1	DL Chili -Teflon Liner 1.0-1.2mm 3.0m	W005921
	DL Chili -Teflon Liner 1.0-1.2mm 4.5m	W005938
	DL Chili -Teflon Liner 1.0-1.2mm 3.5m	W007961
	DL Chili -Teflon Liner 1.0-1.2mm 5.0m	W007962

No.	Description	Order
1	Swan Neck 50°	SP004585
2	Front Handle	4303310
2-1	Connecting Ring	4295160
3	Switch	4182500
4	Cable Assembly 3m 4.5m
5	Switch Control Wire Plug
6	Link Piece	3146280
6-1	Cable Support	3133490
7	Cover φ23×1.5
8	Rear Cable Support	3137900
9	Rear Handle	4270500
10	Rear Connector Nut	9592105
11	Kemppi Euro Central Connector	9580159
12	Jacket Nut	SP9580158

\
