| 规格: | |
|---|---|
| Quantity: | |
TR300 Air Cooled MIG GUN
Tonyweld
85159000
TR300 Air Cooled MIG GUN Air Cooled MIG GUN CO2 mi
Tregaskiss 300A
1piece a plastic box
3M or 4M or 5M or according to customer request
Jiangsu, China (Mainland)
350A mixed gases
60%
euro / mille /bnd connector and etc
030”-1/16”(0.8-1.6mm)
| TR300 Air Cooled MIG GUN | | | ||
| Technical Data： | Rating: 350A CO2/200A Mixed Gases | | | |
| | Duty Cycle: 60% | | | |
| | Wire Size: .030”-1/16”(0.8-1.6mm) | | | |
| | Type | 10ft(3.0m) | 12ft(3.5m) | 15ft(4.5m) |
| | TR300 MIG GUN Miller Connector | 3010M | 3012M | 3015M |
| | TR300 MIG GUN Tweco Connector | 3010T | 3012T | 3015T |
| | TR300 MIG GUN Lincoln Connector | 3010L | 3012L | 3015L |
| | TR300 MIG GUN Euro Connector | 3010E | 3012E | 3015E |
| | | | | |
| No. | Description | Order | | |
| A | Nozzle 3/8″ 9.5mm Flush Copper | 401-4-38 | | |
| | Nozzle 1/2″ 12.7mm 1/8″ Recess Copper | 401-4-50 | | |
| | Nozzle 5/8” 15.9mm 1/8” Recess Copper | 401-4-62 | | |
| | Nozzle 3/4” 19mm 1/8″ Recess Copper | 401-4-75 | | |
| | Nozzle 5/8” 15.9mm 1/8” Stick Out Brass | 401-8-62 | | |
| | Nozzle 5/8” 15.9mm 1/4” Stick Out Copper | 401-9-62 | | |
| | Nozzle 1/2” 12.7mm 1/4” Stick Out Brass | 401-44-50 | | |
| | Nozzle 1/2” 12.7mm 1/8” Stick Out Brass | 401-48-50 | | |
| | Nozzle 1/2″ 12.7mm 1/8” Recess Brass | 401-42-50 | | |
| | Nozzle 3/8″ 9.5mm 1/16” Recess Brass | 401-40-38 | | |
| B | Contact Tip .230” 0.6mm | 403-23 | | |
| | Contact Tip .030” 0.8mm | 403-30 | | |
| | Contact Tip .035” 0.9mm | 403-35 | | |
| | Contact Tip .040” 1.0mm | 403-40 | | |
| | Contact Tip .045” 1.2mm | 403-45 | | |
| | Contact Tip .052” 1.4mm | 403-52 | | |
| | Contact Tip 1/16” 1.6mm | 403-116 | | |
| C | Gas Diffuser (1/4-20Thd) | 404 | | |
| D | Nozzle Retainer | 402-3 | | |
| E | Neck Insulator | 402-11 | | |
| F | Liner for .035″-.045″(0.9-1.2mm) 10FT(3.0m) | 415-35-10 | | |
| | Liner for .035″-.045″(0.9-1.2mm) 15FT(4.6m) | 415-35-15 | | |
| | | | | |
| No. | Description | Order | | |
| 1 | Swan Neck 45° | 305-45 | | |
| | Swan Neck 60° | 305-60 | | |
| 2 | Torch Body Assembly | 407 | | |
| 3 | Handle | 410 | | |
| 4 | Switch | 411-1 | | |
| 5 | Switch The Trigger | 411-2X | | |
| 6 | End Fitting | 308 | | |
| 7 | Cone Nut | 409 | | |
| 8 | Cable Ball Joint & Support Spring Big | 400.1010B | | |
| 9 | Cable Assembly | | | |
| 10 | Euro Direct Plug Kit | 1199E | | |
| 10-1 | Rear Handle | 501.2248 | | |
| 10-2 | Adaptor nut | 4861 | | |
| 10-3 | Euro Central Connector | 5060 | | |
| 11 | Rear Handle American Brand | 2520047 | | |
| 12 | Control Wire (Tweco/Miller) | MAK-354 | | |
| 12-1 | Control Wire (Lincoln) | LAK-354 | | |
| 13 | Tweco Central Connector | 2200103 | | |
| 14 | Miller Central Connector | 2200101 | | |
| 15 | Lincoln Central Connector | 2200099 | | |
| 15-1 | Gas Tube | LKGAS | | |
