51PK TIG Kit Gas Lens for WP 17 18 26 Torch Accessories Spares Parts
Tonyweld
85159000
51PK TIG Kit Gas Lens for WP 17 18 26 Torch Acces
for wp17/18/26
as customer request
Jiangsu, China (Mainland)
collet body / collet / glass cups
属性值
属性值
| 51PK TIG Kit Gas Lens for WP 17 18 26 Torch Accessories Spares Parts | ||
| 51 pieces TIG Torch Accessories (consumables) | ||
| Quantity | Description | Reference number |
| TIG Gasket for gas lens cup 2pcs | ||
| 1PC | Insulators Cup Gasket | 18CG |
| 1PC | Insulators Cup Gasket | 54N01 |
| TIG Back Cap 3pcs | ||
| 1PC | Back Caps ( Long ) | 57Y02 |
| 1PC | Back Caps ( Medium ) | 57Y03 |
| 1PC | Back Caps ( Short ) | 57Y04 |
| TIG Alumina Nozzles 10pcs | ||
| 1PC | size 4, D6.5 x 47mm | 10N50 |
| 2PCS | size 5, D8.0 x 47mm | 10N49 |
| 3PCS | size 6, D9.5 x 47mm | 10N48 |
| 3PCS | size 7, D11 x 47mm | 10N47 |
| 1PC | size 8, D12.5 x 47mm | 10N46 |
| TIG Medium Alumina Gas Lens Cups 8pcs | ||
| 2PCS | size 5, D8.0 x 42mm | 54N17 |
| 2PCS | size 6, D9.5 x 42mm | 54N16 |
| 2PCS | size 7, D11 x 42mm | 54N15 |
| 2PCS | size 8, D12.5 x 42mm | 54N14 |
| TIG Collets 10pcs | ||
| 1PC | 0.040" & 1.0mm | 10N22 |
| 3PCS | 1/16" & 1.6mm | 10N23 |
| 3PCS | 3/32" & 2.4mm | 10N24 |
| 3PCS | 1/8" & 3.2mm | 10N25 |
| TIG Collet Bodies 10pcs | ||
| 1PC | 0.040" & 1.0mm | 10N30 |
| 3PCS | 1/16" & 1.6mm | 10N31 |
| 3PCS | 3/32" & 2.4mm | 10N32 |
| 3PCS | 1/8" & 3.2mm | 10N28 |
| TIG Medium Gas Lens Collet Bodies 8pcs | ||
| 2PCS | 0.040" & 1.0mm | 45V24 |
| 2PCS | 1/16" & 1.6mm | 45V25 |
| 2PCS | 3/32" & 2.4mm | 45V26 |
| 2PCS | 1/8" & 3.2mm | 45V27 |
